Pyrolysis plant
"Bars - tire"

Recycling of car tires without preliminary crushing in a shredder. Obtaining heating oil.

ask a question characteristics

About the company

Pyroliz LLC is engaged in the design and manufacture of equipment for the processing and disposal of waste (plastic, tires, solid waste) in order to obtain additional energy resources (fuel, gas, electricity, heat).

A range of equipment has been developed for various types of waste.

Bars - solid waste
Bars - tire
Bars - oil refinery
Bars - oil sludge
Bars - plastic

Bars -tire 20

The unit processes whole car tires (without preliminary crushing in a shredder).

Product yield:
- Fuel up to 60%,
- Coal up to 30%.
- Gas up to 20%
- Metal cord 10%

- Uninterrupted operation of the unit 24/7.
- Processes tires up to 20" radius.
- Heat-resistant stainless steel reactor.
- Power consumption 6 kW.
- Process automation.
- Processing up to 15 tons.
- Connection of a 100 kW electric generator.
- Production of heat and steam.
- Heating of the reactor on associated gas.
- Separation of raw materials (coal, metal, fuel, gas).
- High three-stage gas purification.
- Installation without a foundation.
- Works in outdoor conditions
- Transportation on a trailer.
- Service 2 people.

Equipment

- Tire recycling plant, can be additionally equipped with a mini refinery.

- Separation of narrow and light fractions.

- Return of still residue back to the pyrolysis plant.

Mini - Refinery - Bars
Overall dimensions of the pyrolysis unit.
Transported in a heavy-duty vehicle. (40" container)
Complete set of the pyrolysis unit "Bars - tire"
At the customer's request, the options can be varied (+ and -)

Download the unit specifications
Complete set of the pyrolysis unit "Bars - tire"
The complex processes tires up to 20 radius, but can be manufactured for processing trucks.

Download commercial offer

Download unit specifications

Device

Loading conveyor

Supplies the tires to the reactor at a preset speed.
Installation reactor

It is made of heat-resistant steel with three compartments (dispenser, retort, unloading)
Screw in the reactor

Designed for tires up to 20" radius. It can withstand high loads and temperatures.
Installation framework

A rigid base for the entire structure. It can withstand dynamic and power loads.
Unloading a metal cord

It is unloaded into a trolley. A sealed door prevents air from entering the reactor.
Gas generator

It is working to start the installation. Generates gas to heat the reactor and generate electricity.
Electric generator

The excess gas from the processing of raw materials is used to generate electricity.
Filter column

Performs purification from mechanical particles, separates the combined-cycle gas mixture into fractions.
Storage capacities

Petroleum products are collected in settling tanks and water is separated from the product.
Градирня

Охлаждает теплоноситель (вода) воздушным вентилятором. Создает циркуляцию во всей системе.
Холодильник

Выгружает и охлаждает угольный остаток из реторты до 40 градусов в вагонетку.
Футеровка

Выполнена из легких материалов, удерживает тепло в реакторе. Хорошо выдерживает динамические нагрузки.
Фильтр -сменный

Возможна комплектация сменными фильтрами для бесперебойной работы установки.
Газовая горелка

Разогревает реторту на всем протяжении до 9 метров. Устойчиво работает на всех горючих газах.
Парогазовый фильтр

Очищает и обезвоживает попутный газ для дальнейшего поступления в электрогенератор и горелку.
Настил-лестницы

Делают обслуживание установки удобным.
Парогенератор

Нагревается от исходящих отработанных газов. Пар добавляется в колонну для лучших характеристик топлива.
Факел

Избыточный газ от переработки сырья сжигается.

Specifications

Installation type

axial auger

Retort diameter

950 мм

Efficiency

15 т

Operating temperature

650 *

Retort material

stainless steel

Installation weight

12 т

Processing raw materials

tires up to 20"

Retort length

9 м

Installation dimensions LxWxH

12 х 2 х 2

Consumption of electricity

6 kW

Mains voltage

380 V

Column height

3,5м

Gas burner

1,5 мВт

Refrigerant capacity

1,5 м3

Getting fuel

9 т

Conveyor length

6 м

The length of the refrigerator

5 м

Service

2 ч

6 Reasons to work with us

01.

Engineering solution

The company has technological solutions for processing various raw materials.

02.

Conducting tests

We will process your raw materials and provide a material balance for the products received.

03.

More than 20 developments

In particular, the pyrolysis and waste recycling processes, the components and mechanisms for the equipment are individually designed.

04.

View in progress

It is possible for clients to look at the operation of the equipment in production.

05.

Environmental friendliness

The equipment meets environmental standards, pollution, and emissions.

06.

Adaptability

There is interest in the equipment on all continents. It is competitive against any challenge.

We will do a test processing of your raw materials in a pyrolysis plant

Let's separate the material balance from the raw materials:
- liquid fraction
- coal residue
- the amount of gas

We divide the liquid product into the fractional composition
of DT, AI, water, and ash residue.

The cost of the test is $1000.

Bars series installations

Bars - Bus

The plant recycles car tires entirely (without pre-crushing in a shredder).

Product Output:
- Fuel up to 60%
- Coal up to 30%
- Gas up to 20%
- Metal cord 10%
Bars - Solid waste

Disposes of solid waste, MSW, plastic, RTI

The yield of the products depends on the morphological composition of the waste.
Humidity has a big effect.
It is able to recycle a wide range of waste.

Productivity ranges from 1 to 20 tons of incoming raw materials.
Bars - REFINERY - cracking

The processing complex is used as an addition to the pyrolysis plants of the Bars family in order to obtain narrow, light fractions.

Mini refinery - "Bars"

The Bars-REFINERY processing complex is used as an addition to the pyrolysis plants of the Bars family, in order to obtain narrow, light fractions.

МИНИ НПЗ БАРС

- Processes up to 20 tons per day.
- Column height is 12 meters.
- Collapsible column on a 3-meter section.
- Quick replacement of the nozzle.
- Convenient, fast service.
- Divides raw materials into narrow fractions.
- Tube oven up to 360 degrees.
- Catalytic cracking.
- Addition of catalysts.
- Adding steam to the column.
- Heating the furnace with associated gas.
- Preparation of raw materials.
- Water cooling (cooling tower).
- Centrifugal gas filter.
- Hot pump.
- Insulated container for 10 m3
- Food containers of 5 m3 each.

Video (recycling tests)

Rutube

Пиролиз лузги подсолнечника

The raw material releases 45% of the liquid fraction. It turns out to be a good coal that can be used. It has a high calorific value.
Пиролиз нефтешламов с песком

The raw materials are processed well in the plant. Enough gas is released to support the process. It takes a lot of energy to evaporate water.
Пиролиз мазута из Анапы

The raw materials came with a large amount of sand 1:20. Sorted raw materials emit a lot of gas and liquid. It takes a lot of gas to evaporate water. We got a good oil product.
Пиролиз угля из Казахстана

The coal contains an oil-based combustible fraction. A lot of energy is spent on evaporation of moisture from the product. We used a lot of gas to heat the retort. A convenient product for recycling.
Пиролиз животной органики

(Pork rind) the residue from the production of meat and bone meal. High fat content. There is a lot of water in the product. The resulting product burns well. There is enough gas to maintain the process
Пиролиз пластика

A large amount of gas is released. The oil product is of good quality, but contains acid due to PVC plastic. It has a negative effect on the life of the retort metal and pipelines.
Пиролиз нефтешламов

The most high-calorie and the best product for obtaining oil fractions up to 90%. There is enough gas to maintain the working process. If there is a lot of water, then more energy is spent for evaporation.
Пиролиз бурого угля из Сибири

There are oil fractions in the product. There is a lot of gas, which is enough for the installation workflow. Economically questionable technology for producing fuel for internal combustion engines.
Пиролиз автомобильного корда с крошкой резины

Good raw materials for processing. Plenty of gas to keep the process running. The heating oil ignites instantly. There are many gasoline fractions.
